Physics Practical Solutions
A/L / Electronics
Experiment No 36
Construction of the transfer characteristic curve between IB and IC of a transistor in common emitter configuration
Order
| Picture | Item Code | Code/ Description |
| DTE025 | EX 36.1 Silicon TransistorA2SD400 | |
| DTE012 | EX 36.10 Connecting wires | |
| EX 36.2 Two 5 kW potential dividerspotentiometer (“B” type) | ||
| EX 36.3 10 kW 1⁄4 kW resistor | ||
| EX 36.4 100 W, 1⁄2 W resistor Instead of all these apparatus the first circuit of the bipolar transistor trainer available in the laboratory can be used | ||
| DTI009 | EX 36.5 Analogue MultimeterRange 10 V | |
| EX 36.6 100 mA ammeter or an analogue multimeter of range 50 mA | ||
| EX 36.7 Analogue multimeter range 25 mA | ||
| EX 36.8 12 V d.c. power supply (or a 6 V accumulator) | ||
| DTE009 | EX 36.9 Circuit board (project / bread board) |
