Physics Practical Solutions
A/L / Electronics
Experiment No 35
Construction of the I-V curve for a forward biased semiconductor diode
Order
| Picture | Item Code | Code/ Description |
| DTE006 | EX 35.1 An 1N 4001 diode | |
| EX 35.2 5 kW linear potential divider (potentiometer B type) | ||
| DTE001 | EX 35.3 100 W 1 W resistor (The first circuit of the semiconductor Diode Trainer available in the school laboratory can be used instead of this set.) | |
| DTI005 | EX 35.4 2 V d. c. power supply | |
| DTI001 | EX 35.5 0 - 1 V voltmeter An analogue multimeter of range 2.5 V can be used for this | |
| DTI009 | EX 35.6 Analogue multimeter with ranges 2.5 mA and 25 mA (a digital multimeter having ranges 2000 mA - 20 mA is more suitable for this) | |
| DTE012 | EX 35.7 Connecting wires | |
| DTE009 | EX 35.8 Bread board / project board |
